opk Cruiser 5 W Ceiling Mounting
opk Cruiser 5 W Ceiling Mounting
opk Cruiser 5 W Ceiling Mounting is a room-dividing system that can be used to create a versatile room utilisation concept.
0.0 Yuan 0.0 Yuan
Door width:
max. 1500mm
Door thickness:
25-32mm
Door weight:
50kg
Height adjustment:
+10mm
Damping:
without, one side, both sides
产品描述
[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[产品参数, 参数]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]

USP



opk Cruiser 5 W Ceiling Mounting is a room-dividing system that can be used to create a versatile room utilisation concept.

The bottom-running system is designed for wooden doors up to 50 kg per door.

The double running tracks for ceiling mounting open up new interior architectures.

Excellent running and damping properties ensure a high-quality user experience.

Icons



The advantages at a glance



• Ceiling mounting
• Wooden doors, height up to 2800 mm, width from 300 mm, thickness 25-32 mm
• 1 or 2-running, bottom-running system, weight load below
• Various surfaces: anodised aluminium, titanium optics
• Easy installation, comfortable height adjustment of the fronts +10 mm
• Stopper positions itself automatically during assembly
• Anti-Jump function

• Carriages with ball-bearing plastic rollers for door leaf weights up to 50 kg ensure extremely light and quiet running

• Both sides damping up to 50kg, Two-way damper with fixation for middle doors

• The opening and closing force are adjustable

Video



Uses



• Office
• Living, eating, bedroom

• Walk-in closet, niche solutions

Certificates



• Tested according to SGS-CSTC EN 15706:2009  Level 3

扫二维码用手机看
未找到相应参数组,请于后台属性模板中添加

Downloads

  • opk

    opk Cruiser 5 W Ceiling catalog.pdf

    Size:
    2022-03-12 17:28:02
  • opk

    -opk Cruiser 5 W Deckenmontage Ceiling Mounting Instruction Montageanleitung.pdf

    Size:
    2020-06-18 15:06:44
  • opk Cruiser 5 all series CAD.dwg

    Size:
    2020-04-29 17:54:45
